4.3.4 Monitor User Operation
4.3.4.1 Menubar
The ’File’ menu of the Monitor User’s main window contains the submenu ’Exit’. After clicking on this
submenu the Supervisor leaves the MTSC application.
The ’Help’ menu contains the items ’About’ and ’Content F1’. Clicking on the submenu ’About’
opens the ’About window’ (see Fig. 4−12) on screen 0. The window shows the actual version of the
MTSC application. Further the window shows some variables of the Java Virtual Machine (VM). Clik-
king on the submenu ’Content F1’ opens the ’MTSC Help window’ (see Fig. 4−13) on screen 0.
4.3.4.2 Toolbar
See also section 4.3.3.2.
The icons on the Toolbar of the Monitor User’s main window are all greyed, i.e. not available.
4.3.4.3 Map Panel of Main Menu
4.3.4.3.1 Map Menu of Map Panel
See also section 4.3.3.3.1 .
The Map menu of the Monitor User’s map panel contains the submenus:
S Refresh:
Refreshes the status indication of all GS indicated in the map panel.
S Edit
Access to Export:
The window ’Save’ appears to save the actual configuration within an *.xml file (see Fig. 4−18).
NOTE: The menu items presented in grey letters are not accessible.
4.3.4.3.2 GS Menu of Map Panel
See also section 4.3.3.3.2 .
The GS menu of the Monitor User’s map panel provides the following submenus:
S Refresh:
Refreshes the status indication of the selected GS.
S Info:
The window ’Configuration Info − <GS name>’ appears in screen 0 (see Fig. 4−21).
S Detailed View
Show:
The ’Detailed Status window’ appears on screen 0 (see section 4.3.2.2).
Detailed View Hide:
The ’Detailed Status window’ disappears on screen 0.
NOTE: The menu items presented in grey letters are not accessible.
