AS 680/682
Installation and Setup Description, Operation and Maintenance
ADS−B
3−2 Ed. 10.07
3.1.2.2 Ground Station AS 682
The following table lists the hardware and software items of the Ground Station AS 682.
Hardware Item P/N Remark
ADS−B Ground Station AS682 cabinet 83142 70200 preassembled, dualized equipment
Signal Processing Unit, AC/DC option 83142 71020 2x
− GTS DG14 83142 71600
−SBC 83142 71230
− SPB 83142 71301
− RXU2 83142 71503 Replaces RXU1, Ref.No. 83142 71502
− AC/DC converter 58142 30500
− AC kit 58142 30600
− Fan Unit 58142 30400
− Dust filter mat 58142 30410
Exchange panel 4/2 35490 28066 used to interconnect RF cables incl. RF divider
− RF divider 49915 28050 used to split RF IN to both SPU/RXU devices
Site Monitor with AC/DC plug−in power supply 61460054 1x
Data Switch (Longshine) for networking 97528 28200 16 port Gigabit Ethernet Switch
Uninterruptible Power Supply Xantos RS1000 97541 28006 2x, incl. opt. UPS WEB/SNMP manager CS121
− UPS WEB/SNMP manager CS121 RS1000 97541 28008
Uninterruptible Power Supply Extension Pack 97541 28007 2x, dedicated to RS 1000 each
GPS antenna 72600 28001 2x, incl. adapter
Option: mounting kit for GPS antenna 58142 50020 2x, incl. mounting tube 34450 28021, 2 clamps
ADS−B RX antenna 97980 28192 1x
Option: Mounting frame for antenna xxxxx xxxxx used individually for antenna mounting on site
AAU (ADS−B Antenna Amplifier Unit) 83142 75200 incl. LNA unit, mounting kit, weather protection
− LNA−Unit incl. housing (option) 83142 75210 incl.lightning protection of RF IN, RF filter
− LNA−Unit incl. housing (option) 83142 75310 incl.lightning prot. of RF IN, RFfilter, input limiter
− LNA−housing mast support (mounting kit) 35380 28051 1x
2x 8 socket strip with 10A fuse; 1x 9 socket strip 60110−202/−212 (part of cabinet)
Cable set AS682 (optional) Refer to 3.1.4.
3.1.3 Hardware Items for RCMS Installation
The following table lists the hardware and software items of the RCMS configuration at remote site.
Hardware Item P/N Remark
Standard Personal Computer Type HP Compaq Evo D530 or similar
Additional subassemblies for standard PC:
− Graphics adapter, dual head Type Matrox G450 or similar
− Ethernet adapter 0, 1 Type Intel Ethernet Pro 100 or similar
TFT−LCD screen monitor 19" monitor
Cable Item P/N Remark
Cable set RCMS dual VGA−cable, power cables
