12
Rear Panel (N5200BR PRO)
The Thecus N5200BR PRO’s rear panel features ports and connectors.
N5200BR PRO Back Panel
Item Description
eSATA Port • eSATA port for high-speed storage expansion
USB Port • USB 2.0 port for compatible USB devices, such as digital
cameras, USB disks, and USB printers
USB Port (target) • For connecting the N5200 to your PC as a mass storage device
4-port Gigabit
Switch
• This 4 port switch can be used for connection sharing
LAN Port • LAN port that can be used for connection sharing
WAN Port • WAN port for connecting to an Ethernet network through a
switch or router
Power Switch • Switch for power supply
System Fan • System fan that exhausts heat from the unit
Power Connector • Connect the included power cords to these connectors
Serial Port • This port is for factory use only
