CUTMASTER A60

PARTS LIST 6-8 Manual 0-4982

6.10 Torch Replacement Parts SL100SV Torch (with Solenoid on Mounting

Tube)

Item No. Qty Description Catalog No.

1 1 Torch Head Assembly without leads (includes items 2, 3, and 14) 9-8220

2 1 Large O-Ring 8-3487

3 1 Small O-Ring 8-3486

4 1 PIP Switch Kit 9-7036

5 1 PIP Plunger and Return Spring Kit 9-7045

6 Automated Leads Assemblies with ATC connectors

  1  25-foot/7.6mLeadsAssemblywithATCconnector  4-3058

  1  35-foot/10.6mLeadsAssemblywithATCconnector  4-3059

  1  50-foot/15.2mLeadsAssemblywithATCconnector  4-3060

7 1 Rack 9-9448

8 1 Mounting Tube 9-9445

9 1 End Cap Assembly 9-7044

10 2 Body, Mounting, Pinch Block 9-4513

11 1 Pin, Mounting, Pinch Block 9-4521

12 1 Torch Holder Sleeve 7-2896

13 1 Pinion Assembly (does not include positioning tube) 7-2827

14 1 Torch Holder Sleeve 7-2896

15 1 Pinion Gear-Short 8-6074

16 1 Handwheel (Torch Holder) 9-4514

 17 1  LowProleTorchHolder(13/8Dia)w/oHardware  9-4515

18 1 Calibrated Torch Holder Bushing 9-4366

 19 1  5/32Diax5/8LgSloedSpringPin  SeeNote1

20 1 3/8-24 x 3/8 Soc Hd Set Screw, Cup Point See Note 1

21 2 1/4-20 x 5/8 Hex Socket Head Screw See Note 1

22 1 #10-24 x 3/8 Hex Socket Set Screw, Cup Point See Note 1

23 1 Solenoid Assembly 9-9447

24 1 Solenoid Cover 9-9446

NOTE 1

Purchase these parts locally.

Thermal Dynamics A60 CUTMASTER Service Manual
