CUTMASTER 40MM
OPERATION Manual 0-5084
4T-14
Type Torch: SL100 With Exposed Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4 9-8253 135 120 180 4.57 0.19 4.8 75 5.2 180 360 0.20 0.25 6.4
0.375 9.5 9-8253 144 120 100 2.54 0.19 4.8 75 5.2 180 360 0.40 0.25 6.4
0.500 12.7 9-8253 146 120 60 1.52 0.19 4.8 75 5.2 180 360 0.80 0.25 6.4
0.625 15.9 9-8253 155 120 40 1.02 0.25 6.4 75 5.2 180 360 1.20 0.28 7.0
0.750 19.0 9-8253 164 120 26 0.66 0.25 6.4 75 5.2 180 360 NR NR NR
1.000 25.4 9-8253 164 120 18 0.46 0.25 6.4 75 5.2 180 360 NR NR NR
1.250 31.8 9-8253 170 120 9 0.23 0.25 6.4 75 5.2 180 360 NR NR NR
Type Torch: SL100 with Exposed Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4 9-8253 142 120 190 4.83 0.19 4.8 75 5.2 180 360 0.30 0.25 6.4
0.375 9.5 9-8253 145 120 120 3.05 0.19 4.8 75 5.2 180 360 0.50 0.25 6.4
0.500 12.7 9-8253 151 120 70 1.78 0.19 4.8 75 5.2 180 360 0.80 0.25 6.4
0.625 15.9 9-8253 162 120 50 1.27 0.25 6.4 75 5.2 180 360 1.00 0.28 7.0
0.750 19.0 9-8253 164 120 34 0.86 0.25 6.4 75 5.2 180 360 NR NR NR
1.000 25.4 9-8253 170 120 20 0.51 0.25 6.4 75 5.2 180 360 NR NR NR
NOTE
* Gas pressure shown is for torches with leads up to 25’ / 7.6 m long. For 50’ / 15.2 m leads, refer to
section 4.02 "Operating Pressure".
** Total flow rate includes plasma and secondary gas flow.
