Thermal Dynamics CutMaster 40MM User Manual

CUTMASTER 40MM
APPENDIX Manual 0-5084
A-4
APPENDIX 4: TORCH CONNECTION DIAGRAMS
A. Hand Torch Connection Diagram
To rch: SL60 / SL100 Hand Torch
Leads: To rch Leads with AT C Connector
Power Supply: with AT C Receptacle
Pilot
Negative / Plasma
Power
Supply
PIP
Switch
Male
ATC Leads
Connector
AT C Female
Receptacle
Pilot
Negative / Plasma
Black
Orange
Torch
Leads
Torch
Head
To Power Supply
Circuitry
Art # A-03797
1
2
5
6
4
3
8
7
1
2
5
6
4
3
8
7
Torch
Switch
Green
White
To Power Supply
Circuitry
B. Mechanized Torch Connection Diagram
To rch: Unshielded Mechanized SL100 Machine To rch
Leads: Leads with AT C Connector and
Remote Pendant Connector
Power Supply: with AT C Female Receptacle
Pilot
Negative / Plasma
Power
Supply
To Remote Control
Remote
Pendant
Connector
PIP
Switch
Not
Used
Male
AT C Leads
Connector
AT C Female
Receptacle
Pilot Lead
Negative / Plasma Lead
Torch
Leads
Torch
Head
Art # A-03798
1
2
5
6
4
3
8
7
To Power Supply
Circuitry
Green
To Power Supply
Circuitry
1
2
5
6
4
3
8
7
Black
White
Green
Black
Orange
White
