CUTMASTER 40MM
Manual 0-5084 OPERATION
4T-19
Type Torch: SL100 With Shielded Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4 9-8253 136 120 180 4.57 0.13 3.2 75 5.2 180 360 0.20 0.20 5.1
0.375 9.5 9-8253 144 120 100 2.54 0.13 3.2 75 5.2 180 360 0.40 0.20 5.1
0.500 12.7 9-8253 149 120 60 1.52 0.13 3.2 75 5.2 180 360 0.80 0.20 5.1
0.625 15.9 9-8253 153 120 40 1.02 0.15 3.8 75 5.2 180 360 1.20 0.20 5.1
0.750 19.1 9-8253 157 120 30 0.76 0.15 3.8 75 5.2 180 360 NR NR NR
1.000 25.4 9-8253 162 120 20 0.51 0.15 3.8 75 5.2 180 360 NR NR NR
1.250 31.8 9-8253 165 120 10 0.25 0.15 3.8 75 5.2 180 360 NR NR NR
Type Torch: SL100 With Shielded Tip
Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per Minute) Standoff Plasma Gas Press Flow (CFH) Pierce Pierce Height
Inches mm (Cat. No.) Volts(VDC) (Amps) Inches Meters Inches mm psi* bar Plasma Total** Delay (Sec) Inches mm
0.250 6.4 9-8253 144 120 190 4.83 0.13 3.2 75 5.2 180 360 0.20 0.20 5.1
0.375 9.5 9-8253 148 120 120 3.05 0.13 3.2 75 5.2 180 360 0.50 0.20 5.1
0.500 12.7 9-8253 152 120 75 1.91 0.15 3.8 75 5.2 180 360 0.70 0.20 5.1
0.625 15.9 9-8253 162 120 45 1.14 0.15 3.8 75 5.2 180 360 1.00 0.20 5.1
0.750 19.1 9-8253 163 120 35 0.89 0.15 3.8 75 5.2 180 360 NR NR NR
1.000 25.4 9-8253 168 120 20 0.51 0.15 3.8 75 5.2 180 360 NR NR NR
NOTE
* Gas pressure shown is for torches with leads up to 25’ / 7.6 m long. For 50’ / 15.2 m leads, refer to
section 4.02 "Operating Pressure".
** Total flow rate includes plasma and secondary gas flow.
To Next Page
