Thermal Dynamics Pak Master 100XL Service Manual

Manual 0-2582 9 INTRODUCTION
2.03 Service Responsibilities
The Service Technician should be familiar with the equip-
ment and its capabilities. He should be prepared to rec-
ommend arrangements of components which will pro-
vide the most efficient layout, utilizing the equipment to
its best possible advantage.
Maintenance work should be accomplished in a timely
manner. If problems are encountered, or the equipment
does not function as specified, contact Technical Services
Department at West Lebanon for assistance.
SECTION 2:
INTRODUCTION
2.01 Scope Of Manual
This Manual provides Service Instructions for Thermal
Dynamics PAK Master
®
100XL Air Plasma Power Sup-
ply.
Refer to Operating Manual (0-2581) for individual oper-
ating procedures. Information in this edition is therefore
particularly applicable to the Troubleshooting and Repair
of the equipment, and is intended for use by properly-
trained Service Technicians familiar with this equipment.
Read this Manual and the Operating Manual, 0-2581,
thoroughly. A complete understanding of the capabili-
ties and functions of the equipment will assure obtaining
the performance for which it was designed.
2.02 General Service Philosophy
Several key points are essential to properly support the
application and operation of this equipment.
A. Application
The equipment should satisfy the customer’s require-
ments as supplied and as described in Section 3 of this
manual. Be sure to confirm that the equipment is capable
of the application desired.
B. Modifications
No physical or electrical modifications other than selec-
tion of standard options and Accessories are to be made
to this equipment.
C. Customer/Operator Responsibilities
It is the customer/operators’ responsibility to maintain
the equipment and peripheral Accessories provided by
Thermal Dynamics in good operating order in accordance
with the procedures outlined in the Operating Manual,
and to protect the equipment from accidental or mali-
cious damage.
D. Repair Restrictions
The electronics consists of Printed Circuit Board Assem-
blies which must be carefully handled, and must be re-
placed as units. No replacement of printed circuit sol-
der-mounted components is allowed except as noted in
this manual.
If to be returned, the replaced Printed Circuit Board As-
semblies must be properly packaged in protective mate-
rial and returned intact per normal procedures.
