APPENDIX I: INPUT WIRING REQUIREMENTS
Input Power Input Current Suggested Sizes (See Notes)
Voltage Freq. 1-Ph 3-Ph 1-Ph 3-Ph
Fuse (Amps) Wire (AWG) Wire (Canada)
(Volts) (Hz) (kVA) (kVA) (Amps) (Amps) 1-Ph 3-Ph 1-Ph 3-Ph 1-Ph 3-Ph
208 50/60 15 12.8 71.5 35.6 80 45 6 8 6 8
230 50/60 15.6 13.2 67.9 33.2 75 40 6 8 6 8
240 50/60 15 12.8 62.4 30.7 70 35 6 8 6 8
380 50/60 17.4 14.2 45.7 21.5 55 25 8 10 8 10
415 50/60 17.6 14.2 42.5 19.8 50 25 8 10 8 10
460 50/60 17.7 15.2 38.4 19.1 45 25 8 10 8 10
575
Requires Transformer Module
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electrical Code
NOTES
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired installations
refer to local or national codes.
Cable conductor temperature used is 167° F (75° C).
An energy limiting fuse UL Class RK-1 (examples: BUSS LPS/LPN-RK or Gould-Shawmut AZK-A6K) should be
used to minimize damage to Plasma Cutting, Welding or power distribution equipment.
NEVER use replaceable element fuses like UL Class H, or "one-time" fuses like UL Class K5.
Flexible cable must have an outside diameter of 0.69 inches (17.5 mm) or greater.
