Thermo Scientific Evolution 600 - Standard Rectangular Cell Holder

Left side
Port for optional
Peltier power supply
Power ON/OFF switch
Power supply
connection
Power cord
Zero
Run
7
8
9
4
5
6
1
2
3
0
.
-
Danger Avoid shock hazard. Always power off the spectrophotometer and
disconnect the power supply from the wall outlet or power strip before
disconnecting the power supply from the spectrophotometer. 
Inside sample compartment
The following illustrations show the locations of the connectors inside the
sample compartment.
Evolution 300
Reference
connector
Sample
connector
