ThermoForma 3771 - Cabinet Center Mullion Heated

CABINET CENTER MULLION Heated Component Identification
Models: 3771 / 3773 / 3775 / 3777 / 3779 / 3787
Export Models: 3772 / 3774 / 3776 / 3778 / 3780 / 3788
MAINTENANCE & REPAIR 45
SEQ DESCRIPTION
10 MULLION PLATE 20 MULLION HEATER 30 TAPE
LOCATE SPLICE APROX. AS SHOWN. DO NOT BEND. TAPE MUST COVER SPLICE.
20
10
20
30
TAPE MAY OVERLAP
1
⁄2 MAX
1
⁄2 MAX
2 MIN / 3 MAX
GROUP - 02
GROUP - 01
LOCATE SPLICE APROX. AS SHOWN. DO NOT BEND. TAPE MUST COVER SPLICE.
10
20
30
TAPE MAY OVERLAP
