ThinkPad R500 - 1080 Intel Turbo Memory Minicard

1080 Intel Turbo Memory Minicard
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 84
v “1040 Palm rest or palm rest with fingerprint reader” on page 88
v “1060 Keyboard” on page 92
Table 16. Removal steps of Intel Turbo Memory
1
1
2
Step Screw (quantity) Color Torque
1 M2 × 3 mm, flat-head, nylon-coated (2) Silver 0.167 Nm
(1.7 kgfcm)
3
98 ThinkPad R500 Hardware Maintenance Manual
