Miscellaneous parts
Table 36. Parts list—Miscellaneous parts
FRU P/N CRU
ID
Screw kit (including nylon-coated screws):
v M2 × 2.7 mm (black), flat head (5)
v M2 × 2.8 mm (silver), flat head (10)
v M2 × 3 mm (silver), flat head (30)
v M2 × 3.5 mm (black), bind head (10)
v M2 × 5 mm (black), flat head (15)
v M2 × 9.5 mm (black), flat head (15)
v M2 × 17mm (black), flat head (15)
v M2 × 17mm (black), micro-bind head (2)
v M2.5 × 4 mm (black), flat head (5)
v M2.5 × 6.5 mm (black), flat head (10)
v M2.5 × 6.5 mm (black), bind head (5)
v M3 × 2.8 mm (black), flat head (4)
v Hex stud (2)
45N5867 N
Seal kit:
v Tape, Cable Fix (20)
v Tape, Cable Fix 10 × 20 (10)
v Tape, Cable Circle (10)
v Tape, Antenna Cable Large (4)
v Tape, LCD FPC (2)
v Adhesive Tape 39 × 4 (4)
43Y9636 N
Base miscellaneous parts:
v Lever, eject
v Bracket, puller eject
v Lock, eject
v Coil Spring, pull lever
v Coil Spring, lock eject/battery latch (2)
v Foot rubber, front (2)
v Foot rubber, rear (2)
v Latch, battery eject
v Shield plate, lower
v Insulation sheet 1
v Lever, wireless switch
v Knob, wireless switch
v Form Battery
44C9564 N
System miscellaneous parts:
v (a) DC in cable assembly
v (b) RJ11 cable assembly
v (c) Optical drive switch cable assembly
v (d) Bracket, Kensington
v (e) Bracket, CPU support
v (f) Bracket, N/B, fan discrete/integ.
v (g) Bracket, VGA, fan discrete/integ.
Note: Italicized letters in parentheses are references to the exploded view
in “Overall” on page 142.
N
192 ThinkPad R500 Hardware Maintenance Manual
44C9565
