ThinkPad T480s - 2030 Hinge Kit; Step Screw (Quantity) 1 M2 × 2.2 MM, Flat-Head, Nylon-Coated; For Access, Remove These Frus in Order

Removal steps of the LCD panel and LCD cable assembly
Step Screw (quantity) Color
Torque
1
M2 × 2.2 mm, flat-head, nylon-coated (4)
Black 0.181 Nm
(1.85 kgf-cm)
3
4
5
When installing:
Ensure that the LCD connector is attached firmly.
2030 Hinge kit
For access, remove these FRUs in order:
• “1020 Base cover assembly” on page 67
94
T480s Hardware Maintenance Manual
