ThinkPad T480s - 1050 M.2 Solid-State Drive

Removal steps of the wireless WAN card
Step Screw (quantity) Color Torque
3
M2 × 2.2 mm, flat-head, nylon-coated (1)
Black 0.181 Nm
(1.85 kgf-cm)
When installing:
Plug the orange cable into the connector labeled MAIN on the card; and plug the blue cable into the
connector labeled AUX on the card.
1050 M.2 solid-state drive
For access, remove this FRU:
• “1020 Base cover assembly” on page 67
70
T480s Hardware Maintenance Manual
