Table 8. LCD FRUs (continued)
No. FRU descriptions
Self-service
CRU
Optional-service
CRU
8 Antenna kit No No
9
LCD cable No No
10
Conventional camera card (available on some models) No No
11
ThinkShutter (for models with only conventional camera)
No No
Miscellaneous parts
Table 9. Miscellaneous part
FRU descriptions
Self-service
CRU
Optional-service
CRU
Screw kit:
• Screw M2 x L2.2, black(9)
• Screw M2 x L4, silver (7)
• Screw M2 x L2.7, black (11)
• Screw M2 x L2.2 + 2.3, black (4)
• Screw M2.5 x L4.5, silver (6)
• Screw M2.5 x L2.2, black (4)
• Screw M2 x L2, black (4)
• Spec
No No
Mechanical miscellaneous kit:
• Microphone rubber
• Docking-station connector bracket
• Trackpad mylar
• Smart card reader mylar
• Ethernet extension connector Gen 2 cover
• Spec
No No
Keyboard removal tool (product part number: 01LX856)
No No
Label kit:
• GEO label
• Spec
No No
Connector and cable guide
This section provides information for Lenovo authorized service technicians to help identify connectors and
cables for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major
FRUs” on page 48 and “LCD FRUs” on page 51.
Note: Depending on your model, some connectors or cables might not be available.
52
T480s Hardware Maintenance Manual
