Removal steps of the hall sensor and hall sensor cable
Step Screw (quantity) Color
Torque
6
M2 × 2.7 mm, flat-head, nylon-coated (1) Silver
0.181 Nm
(1.85 kgf-cm)
When installing:
Ensure that the connectors are attached firmly.
1170 Trackpad cable and trackpad
For access, remove these FRUs:
• “1020 Base cover assembly” on page 67
• “1100 Built-in battery” on page 74
82
T480s Hardware Maintenance Manual
