Removal steps of the dc-in cable and power button card
Step Screw (quantity) Color Torque
4
M2 × 2.7 mm, flat-head, nylon-coated (1)
Black 0.181 Nm
(1.85 kgf-cm)
When installing:
Ensure that the connectors are attached firmly.
1210 LCD unit
For access, remove this FRU:
• “1020 Base cover assembly” on page 67
Chapter 8. Removing or replacing a FRU 89
