• “1210 LCD unit” on page 89
• “2010 LCD bezel cover and LCD bezel” on page 93
Removal steps of the hinge kit
Step Screw (quantity) Color
Torque
1
M2.5 × 2.2 mm, flat-head, nylon-coated (4)
Bronze 0.294 Nm
(3.0 kgf-cm)
2040 ThinkShutter, camera card, and LED/camera cable (for models with
only conventional camera)
For access, remove these FRUs:
• “1020 Base cover assembly” on page 67
• “1210 LCD unit” on page 89
• “2010 LCD bezel cover and LCD bezel” on page 93
• “2020 LCD panel and LCD cable assembly” on page 93
• “2030 Hinge kit” on page 94
Removal step of the ThinkShutter
Chapter 8. Removing or replacing a FRU 95
