3. Insert the tabs c and d into the two dents near the two screw heads as shown 5 .
c d
4. Pivot the tool in the direction as shown to release the keyboard 6 . Push the keyboard in the direction as
shown by arrows
7 to release the latches from the keyboard bezel.
5. Pivot the keyboard slightly upward as shown by arrow 8 . Then turn the keyboard over as shown by
arrow
9 .
64 T480s Hardware Maintenance Manual
