12-24V UNIVERSAL SOLAR KIT
F - FAQ
Symptoms Possible causes Solutions
The LEDs on the circuit board
light up faintly and the gate
doesn’t open
Batteries discharged
Disconnect the solar kit from the
motorised gate and allow the solar
panel to charge the battery for at least
48 hours
The circuit board reboots
when movement is attempted
or an L1L2 or L1L3 error code
is displayed
Batteries discharged
Disconnect the solar kit from the
motorised gate and allow the solar
panel to charge the battery for at least
48 hours
Battery lasts less than 10
opening/closing cycles
Solar panel is charging
battery incorrectly due
to its orientation.
Overconsumption of
power.
Reorient the solar panel to face south
and make sure the solar panel is
delivering 21V in full summer sun or
18V in winter sun.
Don’t use the board to power external
devices other than those accessories
designed to work with the motor drive.
Make sure the motor’s power
consumption isn’t too high.
Batteries discharge in 1 week
Solar panel or charging
module connected
backwards
Check solar panel and charging
module connections
G - TECHNICAL AND LEGAL INFORMATION
1 - TECHNICAL CHARACTERISTICS
2 Lead batteries 12V Voltage 4Ah Capacity
Solar panel
Power: 20W
Rated voltage: 18V
Rated current: 1.11A
Solar panel dimensions 450 x 340 x 15mm
Battery box dimensions 250 x 225 x 130mm
Battery dimensions 90 x 101 x 70mm
Protection rating IP44
Operating temperature -20°C to +60°C
