Page #29 background image
TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 0 09/01/21 Thomson Technology
25
3.6.1.17.GENERATOR FAULT STATUS
The LCD screen displays the current status of the Generator Supply. The
following statuses can be displayed:
Normal
Gen Limit Switch Fail
Gen Switching Device Failed
3.6.2. LCD DISPLAY MODE OPERATION
The Lexan faceplate Up & Down arrow pushbuttons can be used for control or
navigation of the LCD screens as follows:
LCD Display Auto Scroll Halt: The automatic scrolling feature can be halted by
pressing and holding the DOWN arrow pushbutton for approximately 2 seconds
(2 LED flashes). The display will remain at the screen that was displayed when
the pushbutton was activated for 255 seconds, and then it will return to the auto
scroll mode.
Manual Advance & Lock-on to Next LCD Display Screen: To manually advance
the LCD to the next screen, press and hold the DOWN arrow pushbutton for
approximately 1 second until the screen changes.
Note: The LCD display will return to the automatic scrolling mode in 255
seconds if no other pushbuttons are used.
Note: For quick advancement to the next display screen, momentarily press the
DOWN arrow pushbutton until the screen changes.
Manual Return & Lock-on to Previous LCD Display Screen: To manually return
to the previous LCD screen, press and hold the UP arrow pushbutton for
approximately 1 second until the screen changes.
Note: The LCD display will return to the automatic scrolling mode in 255
seconds if no other pushbuttons are used.
Note: For quick advancement to the previous display screen, momentarily
press the UP arrow pushbutton until the screen changes.
3.6.3. SYSTEM STATISTICS
The SYSTEM STATISTICS menu displays the following events:
o Total Number of Transfers
