TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 0 09/01/21 Thomson Technology
36
schedule is required at the same time; a 7-day period may be selected, this will
have the test repeat each week at the same time and interval. If the generator
set is to be exercised once a month, a 28-day system rollover should be
selected.) The week and day of week can be selected from any one of the 4
weeks in the list, the test will then repeat at this selected time and interval.
NOTE:
The Plant Exercise Load or No Load operation setting is
located in System Config sub-menu. Refer to Section
#4.6.5.11 for programming information
4.6.4. SYSTEM OPTIONS
4.6.4.1. Version
Factory enabled for operation based on the TSC 80e controller.
NOTE:
This sub-menu item cannot be accessed with user or
Master Password.
4.6.5. SYSTEM CONFIG
4.6.5.1.System Voltage
Twelve system voltage setpoints can be programmed in software for the TSC
80e controller (i.e. 120, 128, 208, 220, 230, 240, 380, 400, 440, 460, 480, 575,
600V). The system voltages are typical system Phase-to-Phase nominal
voltages.
NOTES
1. For 3 phase 3 wire or high voltage applications utilizing
potential transformers with 120V or 128V nominal secondary
voltage, the controller must be programmed with 120V or 128V
setting. Terminal #43 input is ignored in this application with
the TSC 80e.
