TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 0 09/01/21 Thomson Technology
28
4.1.4. PASSWORD ENTRY PROCEDURE
To enter the programming mode, follow the procedure as shown:
1. Press the ENTER key to obtain the Password Main Menu. The “PASSWORD
ENTRY & RESETS” prompt will appear).
2. Press the ENTER key a second time to obtain the Password Sub Menus. The
“USER PASSWORD” prompt will appear). If the USER password is to be
entered, proceed to step #4.
3. Press the DOWN arrow key to select USER or MASTER password sub-menu
4. Once the USER or MASTER sub-menu is selected, press the ENTER key
again to allow password number entry (an asterisk (
*
) should appear to signal
data entry is possible).
5. Use the UP arrow key to adjust the right-hand digit, and if required use the
DOWN arrow key to adjust the left-hand digit. Once the desired number is
displayed, press ENTER key to accept the value.
NOTES
- The USER password can be modified only when the
MASTER Password is used and the “SET
PASSWORD” prompt is displayed.
- The MASTER Password cannot be changed.
- If programming menu is exited the password must be
re-entered.
4.2. SOFTWARE PROGRAMMING PROCEDURE
Once the correct password is entered and access is provided to the Programming menus, the
following procedure is required to locate and view/change a specific program value.
1. Press the DOWN or UP keys to scroll through the programming menus.
2. Once the selected program menu is displayed, press the ENTER key to view the sub-
menus available.
3. Press the DOWN or UP keys to scroll through the programming sub-menus available.
4. Once the selected program sub-menu item is displayed, press the ENTER key to
change the sub-menu item to a different value. An asterisk (
*
) must appear to signal
data entry is possible.
