TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 0 09/01/21 Thomson Technology
26
o Number of Hours Controller is energized
o Number of Hours Load is on Generator
o Number of Hours Load is on Utility
o Total Number of Transfers due to source failure
The TSC 80e has the maximum number of events memory as follows:
o Hours Max = 65,535 Hours 59 Minutes 59 seconds for Load on Gen
o Hours Max = 65,535 Hours 59 Minutes 59 seconds for Load on Util
o Total Transfers = 65,535
o Maximum Logged Events = 32 - Ring buffer
3.6.4. DATALOG MENU
The DATALOG menu displays the recorded data logging for the following events:
The TSC 80e will record the following data, and will time/date stamp when the event
occurred.
System Power On Gen Test Start
DST Activated Gen Test Stop
DST De-Activated Util Test Start
Load on Gen Util Test Stop
Load on Util
Black Start Util
Black Start Gen
Data Log Cleared
Fault on Util Xfr
Fault: Util Limit
Fault: Util Switch
Fault on Gen Xfr
Fault: Gen Limit
Fault: Gen Switch
Fault Reset
For Each phase (A, B, C) of Gen and
Utility; Under Voltage, Over Voltage,
Under Frequency, Over Frequency
