TSC 80e TRANSFER SWITCH CONTROLLER
PM091 Rev 0 09/01/21 Thomson Technology
40
4.6.5.8.Secure Mode
The TSC 80e controller can be programmed in software to inhibit the test
pushbuttons on the Lexan faceplate, for security purposes. To inhibit the test
pushbuttons, program as YES.
NOTE
1. The Secure mode factory default setting is NO
4.6.5.9.Auto Test
This is a status menu only to indicate if the controller is currently set to
Automatically test the generator set as initiated by the front faceplate AUTO
EXERCISE pushbutton. This menu item is not programmable.
4.6.5.10.Dual Event Test
The TSC 80e controller can be programmed in software to select a Dual event
test (i.e. The first programmed Plant exercise event will perform a Load test,
then the second programmed Plant exercise event will perform, a no-load test
will be performed). To select a Dual Event Test, program as YES.
4.6.5.11.Xfr on Load Test
The TSC 80e controller can be programmed in software to select the desired
Plant Exercise testing mode (i.e. load test with transfer or no-load test) for the
programmable exercise function or for a remotely initiated Test mode. To
select a Xfer on Load test, program as YES.
NOTES
1. The No-Load Test mode is the factory default setting.
2. Should utility power fail during a no-load test operation, the
load will automatically transfer to the generator and will re-
transfer back when utility power is restored to within normal
conditions. The engine will continue to run until the 30 minute
exercise time delay period expires.
