Page #120 background imageLoading...
Page #120 background image
© 2013 Thorlabs GmbH118
DCx Cameras
Parameter
Description
[AWB]
WHITEBALANCE
Auto white balance
see also is_SetAutoParameter()
Example of a profile file
[DISPLAY]
PIXEL_FORMAT = 0 // 0 = RGB32, see uc480.h for defined formats
RENDER_MODE = 1 // 1 = IS_SET_DM_DIB, 4 = IS_SET_DM_DIRECT3D, see uc480.h for defined render modes
FIT_TO_WINDOW = 1 // 0 = No scaling, 1 = Scale image to window
[TIMING]
PIXELCLOCK = 30 // MHZ
FRAMERATE = 100 // 0 = min, 100 = max
EXPOSURE = 50 // 0 = min, 100 = max
[COLOR]
CORRECTION_FACTOR = 100 // 0 = 0.0, 100 = 1.0
SATURATION_U = 120 // 0 = 0.0, 200 = 2.0
SATURATION_V = 120 // 0 = 0.0, 200 = 2.0
[IMAGE_PARAMETERS]
EDGE_ENHANCEMENT = 0 // 0 = disable, 1 = weak, 2 = strong
GAMMA = 160 // 100 = 1.0, 220 = 2.2
[AES_AGC_AFR]
EXPOSURE = 1 // 1 = on, 0 = off
GAIN = 1 // 1 = on, 0 = off
FRAMERATE = 0 // 1 = on, 0 = off
SPEED = 50 // 0 = min, 100 = max
SKIPFRAMES = 0 // 0 = min, 100 = max
[AWB]
WHITEBALANCE = 1 // 1 = on, 0 = off
SPEED = 50 // 0 = min, 100 = max
SKIPFRAMES = 0 // 0 = min, 100 = max
See also:
"Choose mode" start dialog
"Profiles" menu
303
76
83
