© 2013 Thorlabs GmbH340
DCx Cameras
4.3.91 is_SetRopEffect
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_SetRopEffect (HIDS hCam, INT effect, INT param, INT reserved)
Description
is_SetRopEffect() enables functions for real-time image geometry modification (Rop = raster operation).
Input parameters
hCam
Camera handle
effect
IS_SET_ROP_MIRROR_UPDOWN
Mirrors the image along the horizontal axis.
IS_SET_ROP_MIRROR_LEFTRIGHT
Mirrors the image along the vertical axis.
Depending on the sensor, this operation is performed in
the camera or in the PC software.
IS_GET_ROP_EFFECT
Returns the current settings.
param
Turns the Rop effect on/off.
0 = Turn off
1 = Turn on
reserved
Reserved. 0 must be passed.
Return values
When used with
IS_GET_ROP_EFFECT
Current setting
IS_CANT_COMMUNICATE_WITH_DRIVER
Communication with the driver failed because no driver
has been loaded.
IS_CANT_OPEN_DEVICE
An attempt to initialize or select the camera failed (no
camera connected or initialization error).
IS_INVALID_CAMERA_TYPE
The camera type defined in the .ini file does not match
the current camera model.
IS_INVALID_CAPTURE_MODE
The function can not be executed in the current camera
operating mode (free run, trigger or standby).
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_INVALID_MODE
Camera is in standby mode, function not allowed
IS_INVALID_PARAMETER
One of the submitted parameters is outside the valid
range or is not supported for this sensor or is not
available in this mode.
IS_IO_REQUEST_FAILED
An IO request from the uc480 driver failed. Possibly the
versions of the uc480_api.dll (API) and the driver file
(uc480_usb.sys) do not match.
IS_NO_SUCCESS
General error message
IS_NOT_CALIBRATED
The camera does not contain any calibration data.
IS_NOT_SUPPORTED
The camera model used here does not support this
function or setting.
IS_NULL_POINTER
Invalid array
IS_SUCCESS
Function executed successfully
IS_TIMED_OUT
A timeout occurred. An image capturing process could
not be terminated within the allowable period.
