THORLABS DCU22 Series User Manual

© 2013 Thorlabs GmbH462
DCx Cameras
Binning
Mode
Horizontal + Vertical
*4
Method
H + V combined, mono/color binning,
H: additive. V: averaging
Factors
2x
Frame rate with 2x binning, 640 x
480 pixels (VGA)
fps
60.0
64.0
Subsampling
Mode
Scaler
Hardware trigger
Mode
Asynchronous
Asynchronous
Trigger delay with rising edge
µs
20 ±0.25
3 ±0.25
*6
Trigger delay with falling edge
µs
33 ±0.25
21 ±0.25
*6
Additive trigger delay (optional)
µs
15 µs...4 s
15 µs...4 s
Power consumption
*5
W
0.3 to 0.7
1.3
*5
** Not yet defined.
*
1
The maximum possible pixel clock frequency depends on the PC hardware used.
*
2
Requires maximum pixel clock frequency.
*
3
Requires minimum pixel clock frequency.
*
4
Use of this function increases the frame rate.
*
5
The power consumption depends on the sensor model and the pixel clock setting.
*
6
Not yet confirmed
*
7
DCC3240N only
*
8
Only for USB3.0 transmission (DCC3240x), with USB2.0 - bit depth is 8 bit.
Please see also the DCC1240x / DCC3240x Application Notes chapter.
