© 2013 Thorlabs GmbH72
DCx Cameras
This setting applies to all connected cameras. If no parameters are stored on the camera, the standard parameters
of this camera model are applied (see also is_Configuration() ).
Boot boost
This mode is not related to DCx Cameras.
Bulk Transfer Size
Via "Bulk Transfer Size" the behavior of the USB sub-system can be set.
Warning
Contact our technical support before changing the value under "Bulk Transfer Size".
COM Ports
The "Additional functions" dialog box allows installing virtual COM ports for communication through the serial
interface of a DCC3240x camera. The following sections show you how to set up and use the serial interface .
Note
This feature is only available for DCC3240x cameras.
You need administrator privileges to install a virtual COM port.
The selected in the uc480 Camera Manager DCC3240x camera has to be marked "Free" and "Available".
Setting up the serial interface on the DCC3240x camera
Before using the serial interface on the camera, one or more virtual COM ports have to be installed on the PC.
Most systems support up to 255 COM ports; COM1 to COM8 are often assigned operating system functions by
default. You can check the current port assignment in the Device Manager on your computer. Some older systems
may not have more than eight ports; in that case you will need to assign the camera to one of these ports.
COM port
In the drop down box, select the number of the port you want to install (default: 100). COM ports in use are
marked "(used)" in the list.
Click this button to install the selected virtual COM port.
During the first installation of a virtual COM port, an additional broadcast port with number 255 is installed. Data
sent to this port will be forwarded to all paired cameras.
You can install any number of virtual COM ports on a single system.
