ThurayaIP Satellite Modem User Guide
9
Button
ButtonButton
Button
Action
ActionAction
Action
Result
ResultResult
Result
Long press Start GPS receiver manually
Modify button Short press Scroll to next option of displayed
menu item when in menu
Long press Toggle Wi-Fi on/off (when not in
menu display)
S
TATUS
/M
ENU
D
ISPLAY
The upper level of the LCD displays status messages and menu items.
Status messages are summarized in the table below.
Display
DisplayDisplay
Display
Description
DescriptionDescription
Description
Powering Off Displayed while ThurayaIP is powering down
Fault {code} A hardware fault exists, preventing operation (see
troubleshooting section for code explanations)
Too Hot A temporary thermal shutdown is about to occur
Battery Hot A temporary thermal shutdown is about to occur
due to battery heating
No SIM No SIM is detected in ThurayaIP
Locked A security code is needed (entered via wMMI)
PIN A SIM pin code is needed (entered via wMMI)
Pointing In pointing mode
GPS old GPS is older than the system time period allows
Disconnected The terminal has no IP connection to the network,
preventing data transfer
Acquiring The terminal is attempting to connect to the network
Tx{rate}/Rx{rate} Transmit and Receive streaming rates in kilobits per
second
Standard Best efforts quality of service in both directions
N
AVIGATION OF THE I
MMI
You navigate among the options available in the iMMI by utilizing the
Menu and Modify buttons. With the unit in its “normal” state displaying
status indicators, you press the Menu button to view and modify Quality
of Service (QoS) settings and LCD display parameters. Pressing the
