10
ThurayaIP Satellite Modem User Guide
Modify button within a Menu option allows you to change the current
setting.
The status display is the default display; after 30 seconds of inactivity, the
display always reverts to the status display. Pressing the Menu button
takes you through a circular list of menu items and then back to the
status display. The two major menu options are the following:
Change Rate: Modify the QoS settings for Transmit and Receive.
LCD Contrast: Modify the contrast on your LCD.
D
ATA
R
ATE
S
ELECTION
• With the unit in the default status display, press the Menu button.
The Change Rate menu option is then displayed.
• Press the Modify button. You are then brought to the first value in
the series of QoS settings.
Change Rate
Change Rate Change Rate
Change Rate
Menu
MenuMenu
Menu
Comment
CommentComment
Comment
Standard Selects Background QoS for both the
transmit and receive directions
Tx: 384Kbps Selects 384Kbps Tx Streaming QoS
Hidden unless external antenna attached
Tx: 16Kbps Selects 16Kbps Tx Streaming QoS
Tx: 32Kbps Selects 32Kbps Tx Streaming QoS
Tx: 64Kbps Selects 64Kbps Tx Streaming QoS
Tx: 128Kbps Selects 128Kbps Tx Streaming QoS
Tx: 256Kbps Selects 256Kbps Tx Streaming QoS
Hidden unless external antenna attached
Rx: 384Kbps Selects 384Kbps Rx Streaming QoS
Hidden unless external antenna attached
Rx: 16Kbps Selects 16Kbps Rx Streaming QoS
Rx: 32Kbps Selects 32Kbps Rx Streaming QoS
Rx: 64Kbps Selects 64Kbps Rx Streaming QoS
Rx: 128Kbps Selects 128Kbps Rx Streaming QoS
