Thytronic DMC3S - DMC3 S - IEC Long Time Inverse Curves (Type LTI)

100
DMC3S - Manual - 08 - 2021
— DMC3S - IEC long time inverse curves (type LTI)
F_51N-IEC-LITB-Char.ai
Note: the set operating time refers to a ratio I/I>inv = 121
1.1
2 3 4 5 6 7 8 9 10 20
0.01
0.1
1
10
100
1000
10000
t [s]
I /I>inv
10 s
60 s
5 s
1 s
0.5 s
0.2 s
0.02 s
0.1 s
t =
tE>inv
·
[(IE/IE>inv) -1]
120
tE>inv
