DMC3S - Manual - 08 - 2021
Signal port
Standard IEC61000-4-4 EN 61000-4-4
Fast transients 5/50 ns (Level 4)
Fast transients 2 kV
Standard IEC 61000-4-6
Conducted electromagnetic fields (Level 3)
• 0.15...80 MHz AM 80% 1kHz 10 V
Standard EC 61000-4-18 EN 60255-22-1
Damped oscillatory wave (Level 3)
• 0.1 MHz and 1 MHz common mode 2.5 kV
• 0.1 MHz and 1 MHz differential mode 1.0 kV
Standard EC 61000-4-12 EN 60255-22-1
Damped oscillatory wave (Level 3)
• Ring wave common mode 2.0 kV
• Ring wave differential mode 1.0 kV
Standard IEC 61000-4-16
Mains frequency voltages (Level 3-4)
• 16
2/3
continuous 100 V
• 16
2/3
1s 300 V
• 50 Hz continuous 100 V
• 50 Hz 1 s 300 V
• 0.015...150 kHz 10-1-1-10 V
DC power input and output port
Standard IEC61000-4-4 EN 60255-22-4
Fast transients 5/50 ns (Level 4)
Fast transients 2 kV, 4kV
Standards
Standard IEC 61000-4-5
High energy pulses (Level 4)
• U
aux
(line-ground) 4 kV
• U
aux
(line-line) 2 kV
Standard IEC 61000-4-6 EN 61000-4-6
Conducted electromagnetic fields (Level 3)
• 0.15...80 MHz AM 80% 1kHz 10 V
Standard EC 61000-4-12 EN 60255-22-1
Damped oscillatory wave (Level 3)
• 0.1 MHz common mode 2.0 kV
• 0.1 MHz differential mode 1.0 kV
Standard IEC 61000-4-16
Mains frequency voltages (Level 3-4)
• 16
2/3
continuous 100 V
• 16
2/3
1s 300 V
• 50 Hz continuous 100 V
• 50 Hz 1 s 300 V
• 0.015...150 kHz 10-1-1-10 V
Standard IEC 61000-4-17
Ripple on DC auxiliary power circuit
DC auxiliary power supply
• Variation 10%
Standard IEC 61000-4-29
Voltage dips, short interruptions and voltage variations on DC input power port immunity tests
• Voltage dip duration with UT=40% 100 ms
• Short interruption duration with UT=0% 50 ms
• Voltage variation duration with Un=80...120% 10 s
— Climate tests
Standard IEN 60068-2-1
Environmental tests: Part 2-1: Tests - Test A: Cold
Standard IEN 60068-2-2
Environmental tests: Part 2-2: Tests - Test B: Dry heat
Standard IEN 60068-2-14
Environmental tests: Part 2: Tests - Test N: Temperature change
Standard IEN 60068-2-33
Environmental tests: Part 2: Tests - Temperature change test guidelines
Standard IEN 60068-2-78
Environmental tests: Test Cab: Damp heat, stationary regime
Standard IEN 60068-3-1
Environmental tests: Part 3: Basic information. Section 1: Cold and dry heat tests
Standard IEN 60068-3-4
