DMC3S - Manual - 08 - 2021
Environmental tests: Part 3-4: Supporting documentation and guidelines. Damp heat tests
— Mechanical tests
Standard EN 60255-21-1 EN 60255-21-2 RMEC01
Vibration, impact, shock and seismic resistance tests for measurement relays and protection equip-
ment
• EN 60255-21-1 Vibration tests (sinusoidal) Class 1
• EN 60255-21-2 Impact and shock tests Class 1
— Insulation test
Standard EN 60255-5
Coordination of the isolation of measurement relays and protection equipment
Test at 50Hz (1 min):
• Auxiliary circuit 2 kV
• Input circuits 2 kV
• Output circuits 2 kV
• Output circuits (between open contacts) 1 kV
• Communication ports 1 kV
Isolation resistance >100 MW
Standard EN 60255-5
Pulse resistance voltage test
Pulse test (1.2/50 ms):
• Auxiliary circuit 5 kV
• Input circuits 5 kV
• Output circuits 5 kV
• Output circuits (between open contacts) 5 kV
Standard EN 61010-1
Insulation test for electrical measurement, control and laboratory equipment
Pollution degree 3
Reference voltage 250 V
Reference category IV
Standard EN 60204-1
Safety of machinery - Electrical equipment of machines. Part 1: General rules
— Reference specifications
Structural and functional requisites for the Multifunctional Protection
and Control Panel for Primary Substations (DV7203) ENEL DMI 9 00016
Protection and control device for HV/MV substation –
Multifunctional feederprotection(MFP) GSTP101_01
Protection and control device for HV/MV substation – Communication profile
(according to IEC 61850) for the MFP GSTP103_01
Cyber security requirements for protection and control devices GSTP901_01
Electrical Diagrams for Protection and control device for HV /
MV substation – Multifunctional Feeder Protection MFP GSTX101_01
— ENEL general standards and tables
Standard IEC61850-x
Communications networks and system for automation of electrical systems
Standard IEE 802.x
Standards relating to the Ethernet port
ENEL unification table DV25
Spring loaded clamps
ENEL unification table DV29
Terminals
ENEL unification table DV1000 rev .01
Data communications, electrical and functional characteristics
ENEL unification table DV801A
Connectors (34 pole)
— Certifications
CE conformity
• EMC Directive 2014/30/EC
• Low Voltage Directive 2014/35/EC
— Environmental Condition
Ambient temperature -10...+55 °C
Storage temperature -20...+70 °C
Relative humidity ≤95 %
Atmospheric pressure 860...1060 kPa
