4 FUNCTIONAL CHARACTERISTICS
4.1 CONFIGURABILITY
The DMC3S multifunctional panel features a modular construction with removable boards.
The panel can be customised for a variety of types of riser; the type of riser can be selected in the
Set \ Base menu.
The firmware selected on the panel defines the measured values of amperometric channel C2, while
the measurements on voltmetric channel V4 must be selected from UE and V2 in the Set \ Base menu.
Measurement channels
Channel Type of channel Measurement
V1 Analogue voltage measurement channel Phase voltage U
L1
V2 Analogue voltage measurement channel Phase voltage U
L2
V3 Analogue voltage measurement channel Phase voltage U
L3
V4 Analogue voltage measurement channel Phase voltage U
E
/ V
sync
C1 Analogue current measurement channel Phase current I
L1
C2 Analogue current measurement channel Phase current I
L2
/ I
SQL
/ I
E
C3 Analogue current measurement channel Phase current I
L3
C4 Analogue current measurement channel Residual current I
E
Channel C2
Correspondence to panel A2 Type of riser Assignment of channel C2
901 MV line stall Measurement I
L2
910 Capacitor stall Measurement I
SQL
922 TFN stall Second measurement channel I
E
907 Coupler stall No measurement (I
L2
)
[1]
905 Transfer bar No measurement (I
L2
)
[1]
917 User HV line stall No measurement (I
L2
)
[1]
Note 1 The system assigns the measurement to I
L2
even when the input is not connected
I
L1
I
L2
I
E
I
SQL
CURRENT INPUTS
MA
C1
C2
C3
MA-1
MA-2
MA-3
MA-4
MA-5
MA-6
I
L3
NONE
Depending on the assignment of channel C2, the measurement and protection functions are given
in the table:
Measurement functions of
channel C2
Measurement assigned to C2 Measurement and protection functions Correspondence to panel A2
None
32P (U
L1
; U
L2
; U
L3
; I
L1
; I
L3
)
51 (I
L1
; I
L3
)
67 (U
12
; U
23
; U
31
; I
L1
; I
L3
; -I
E
)
46 (not used)
51SQL (not active)
905 - 907 - 917
I
L2
32P (U
L1
; U
L2
; U
L3
; I
L1
; I
L2
; I
L3
)
51 (I
L1
; I
L2
; I
L3
)
67 (U
12
; U
23
; U
31
; I
L1
; I
L2
; I
L3
)
46 (U
L1
; U
L2
; U
L3
; I
L1
; I
L2
; I
L3
)
51SQL (not active)
901
I
SQL
32P (U
L1
; U
L2
; U
L3
; I
L1
; I
L3
)
51 (I
L1
; I
L3
)
67 (U
12
; U
23
; U
31
; I
L1
; I
L3
; -I
E
)
46 (not used)
51SQL
910
Second measurement channel
I
E
(51N)
32P (U
L1
; U
L2
; U
L3
; I
L1
; I
L3
)
51 (I
L1
; I
L3
)
67 (U
12
; U
23
; U
31
; I
L1
; I
L3
; -I
E
)
46 (not used)
922
