3 TECHNICAL CHARACTERISTICS
3.1 GENERAL INFORMATION
— Mechanical characteristics
Installation Rack 19” 3U
Dimensions (H x W x D) 133 x 483 x 344
Terminals Screw clamps
Maximum wire cross section 4 mm
2
Weight 4.7 kg
— Electromagnetic compatibility (EMC)
Standard EN 61000-6-2
Part 6-2: Generic standards - Immunity for industrial environments
Standard EN 61000-6-4
Part 6-4: Generic standards - Emissions for industrial environments
Standard EN 61000-4-2, EN 61000-4-2/A1,
EN 61000-4-2/A2
Electrostatic discharge immunity test
Standard EN 61000-4-3
Radiofrequency electromagnetic field immunity test
Standard EN 61000-4-4
Electrical fast transient immunity test
Standard EN 61000-4-5
Pulse immunity test
Standard EN 61000-4-6, EN 61000-4-6/A1
Immunity to conducted disturbances induced by radiofrequency fields
Standard EN 61000-4-8, EN 61000-4-8/A1
mains frequency magnetic field immunity test
Standard EN 61000-4-10, EN 61000-4-10/A1
Damped oscillatory magnetic field immunity test
Standard EN 61000-4-11
Immunity test for voltage dips, brief interruptions and voltage variations
Standard EN 61000-4-12
Oscillatory wave immunity test
Standard EN 61000-4-16, EN 61000-4-16/A1
Immunity test for conducted common mode disturbances in the frequency range 0 to 150 kHz
Standard EN 61000-4-29
Immunity test for voltage dips, brief interruptions and voltage variations on DC power ports
Standard EN 55011, 55011/A1, 55011/A2
Industrial, scientific and medical radiofrequency equipment (ISM) - Radiodisturbance characteris-
tics - Limits and measurement methods
Standard EN 50160
Characteristics of public electrical power grid voltage
— Disturbance immunity tests
Enclosure door
Standard IEC 61000-4-2 EN 60255-22-2
Electrostatic discharge (Level 4)
• Contact discharge 8 kV
• Air discharge 15 kV
Standard IEC 61000-4-3 EN 61000-4-3
Radiofrequency electromagnetic fields (Level 3)
• 80...3000 MHz AM 80% 10 V/m
• 900...1980 MHz MHz Pulse modulated 10 V/m
Standard IEC 61000-4-8 EN 61000-4-8
Magnetic field 50 Hz (Level 5)
• 50 Hz continuous 100 A/m
• 50 Hz 1 s 1 kA/m
Standard IEC 61000-4-10 EN 61000-4-10
Damped oscillatory wave (Level 5)
• Damped oscillatory wave 0.1 MHz 100 A/m
• Damped oscillatory wave 1 MHz 100 A/m
Ground port
Standard IEC61000-4-4 EN 60255-22-4
Fast transients 5/50 ns (Level 4)
• Fast transients 4 kV
Standard IEC 61000-4-6 EN 61000-4-6
Conducted electromagnetic fields (Level 3)
• 0.15...80 MHz AM 80% 1kHz 10 V
