FUNCTIONS
RELAY
KS1-1 K1-2 K1-3 K1-4 K1-5 K1-6
Anomaly (Self test)
Start of first protection threshold 27CC (80.S-ST-K)
Trip of first protection threshold 27CC (80.S-ST-K)
Start of first protection threshold 32P (P1>ST-K)
Trip of first protection threshold 32P (P1>TR-K)
Start of second protection threshold 32P (P2>ST-K)
Trip of second protection threshold 32P (P2>ST-K)
Start of first protection threshold 46 (I2>ST-K)
Trip of first protection threshold 46 (I2>TR-K)
Start of second protection threshold 46 (I2>>ST-K)
Trip of second protection threshold 46 (I2>TR-K)
Start of first protection threshold 50/51 (I>ST-K)
Trip of first protection threshold 50/51 (I>TR-K)
Start of second protection threshold 0/51 (I>>ST-K)
Trip of second protection threshold 50/51 (I>>TR-K)
Start of third protection threshold 50/51 (I>>>ST-K)
Trip of third protection threshold 50/51 (I>>>TR-K)
Start of fourth protection threshold 50/51 (I>>>>ST-K)
Trip of fourth protection threshold 50/51 (I>>>>TR-K)
Start of first protection threshold 50N/51N (IE>ST-K)
Trip of first protection threshold 50N/51N (IE>TR-K)
Start of second protection threshold 0N/51N (IE>>ST-K)
Trip of second protection threshold 50N/51N (IE>>TR-K)
Start of third protection threshold 50N/51N (IE>>>ST-K)
Trip of third protection threshold 50N/51N (IE>>>TR-K)
Start of first protection threshold 51N(Eme) (IEeme>ST-K)
Trip of first protection threshold 51N(Eme) (IEeme>TR-K)
Start of first protection threshold 51N(E) (INe>ST-K)
Trip of first protection threshold 51N(E) (INe>TR-K)
Start of second protection threshold 1N(E) (INe>> ST-K)
Trip of second protection threshold 51N(E) (INe>>TR-K)
Start of first protection threshold 51(SQL) (ISQL>ST-K)
Trip of first protection threshold 51(SQL) (ISQL>TR-K)
Start of first protection threshold 59 (U>ST-K)
Trip of first protection threshold 59 (U> TR-K)
Start of second protection threshold 9 (U>>ST-K)
Trip of second protection threshold 59 (U>>TR-K)
Start of first protection threshold 59N (UE>ST-K)
Trip of first protection threshold 59N (UE>TR-K)
Start of second protection threshold 9N (UE>>ST-K)
Trip of second protection threshold 59N (UE>>TR-K)
Start of first protection threshold 59N(Eme) (UEeme>ST-K)
Trip of first protection threshold 59N(Eme) (UEeme>TR-K)
Start of first protection threshold 67 (IPD>ST-K)
Trip of first protection threshold 67 (IPD>TR-K)
Start of second protection threshold 7 (IPD>>ST-K)
Trip of second protection threshold 67 (IPD>>TR-K)
Start of third protection threshold 67 (IPD>>>ST-K)
Trip of third protection threshold 67 (IPD>>>TR-K)
Start of fourth protection threshold 67 (IPD>>>>ST-K)
Trip of fourth protection threshold 67 (IPD>>>>TR-K)
Start of first protection threshold 67N (IED>ST-K)
Trip of first protection threshold 67N (IED>TR-K)
Start of second protection threshold 67N (IED>>ST-K)
Trip of second protection threshold 67N (IED>>TR-K)
Start of third protection threshold 67N (IED>>>ST-K)
Trip of third protection threshold 67N (IED>>>TR-K)
Start of fourth protection threshold 67N (IED>>>>ST-K)
Trip of fourth protection threshold 67N (IED>>>>TR-K)
