TMQ AP9 - Remote Mode Options; Remote Modes r-1 to r-5

TMQ AP9 Autopilot (V6.0 - 965) Page 45 of 51 31/1/2017
Remote Mode Option Details (908)
r-1 Remote Mode 1 ( 2 Standard TMQ Remotes)
· Remote Unit 1 on Input “Wiper 1” with Control Line “Select 1” being held
Negative for Auto, Positive for Power Steer.
· Remote Unit 2 on Input “Wiper 2” with Control Line “Select 2” being held
Positive for Power Steer.
· Auto Selected on Input “Wiper 2” with Control Line “Select 2” being held
Negative if Control Line “Select 1” not used.
· No voltage on Control Line “Select 1” or Control line “Select 2”, Autopilot
returns to Standby.
r-2 Remote Mode 2 (TMQ Active Remote)
This mode can also be used for 1 only Remote with PB selection
Wiper 1 input, Sel 1 pulsed high for power steer.
r-3 Remote 3 (1 hand remote plus External Auto Select, External
Power Steer Input ie Steering Lever)
· Remote Input on Control Line “Select 1” and Input “Wiper 1”.
· Control Line “Select 2” pulsed Negative for Auto Selected on Main Encoder.
· Control Line “Select 2” pulsed Positive for Power Steer from steering lever
connected to Input “Wiper 2”.
r-4 Remote 4 (1 hand remote plus External Auto or Power Steer
select, control by Encoder.)
· Remote Input on Control Line “Select 1” and Input “Wiper 1”.
· Control Line “Select 2” pulsed Negative for Auto Selected on Main Encoder.
· Control Line “Select 2” pulsed Positive for Power Steer on Main Encoder.
· Steering lever Input on “Wiper 2” in Standby.
r-5 Remote 5 (2 Remote Power Steer stations plus a Steering Lever at
the Main Station)
· Control Line “Select 2” Pulsed Negative allows Power Steer Input on Control
Line “Select 1”.
· Control Line “Select 2” Pulsed Positive allows Power Steer Input on
“Wiper 1”.
· Steering lever Input on “Wiper 2” in Main Power Steer.
