Signal Processing Box
Gain
Variable range : +12 dB to –60 dB, –
∞ dB, 0.5 dB steps, polarity Inversion
Additional function : Muting function (input only)
Compressor/Noise gate (C/G)
Compressor Threshold : -16 dB
*
to +24 dB
*
1 dB steps * 0 dB = 0.775V
Compressor Ratio : 1 : 1, 2 : 1, 3 : 1, 4 : 1, 8 : 1, 12 : 1, 20 : 1,
∞ : 1
Compressor Attack time : 0.02, 0.1, 0.2, 0.5, 0.7, 1.0, 1.5, 2, 3, 5, 7, 10, 20, 50, 70, 100 ms
Compressor Release time: 10, 20, 50, 70, 100, 120, 150, 200, 250, 350, 700 ms
1, 2, 3, 5 sec
Compressor Sync : OFF, Group 1-5
Gate Threshold : -72 dB
*
to -26 dB
*
1 dB steps * 0 dB = 0.775V
Gate Attack time : 0.1, 0.5, 1.0, 2, 5, 10, 50, 100 ms
Gate Release time : 20, 70, 120, 200, 250, 350, 700, 2000, 5000 ms
Parametric Equalizer (PEQ)
No. of adjustment bands : 10 Bands
Filter Type Center Frequency Boost/Cut Q
PEQ 20 Hz to 20 kHz
1/24 octave band or
continuous variable type
(effective figure: 3 digits)
±12 dB
0.1 or 0.5 dB
steps
0.267 - 69.249
(96points)
Filter Type Cut-off Frequency Q
HPF(6 dB)
LPF(6 dB)
---
HPF(12 dB)
LPF(12 dB)
20 Hz to 20 kHz
1/24 octave band or
continuous variable type
(effective figure: 3 digits)
0.500 - 2.563
(51points)
Additional function : Band-bypass function, Bypass-all function
Amplitude frequency characteristic graph indication
