Graphic Equalizer (GEQ)
No. of adjustment bands : 10 Bands
Filter Type Center Frequency Boost/Cut Q
PEQ 20 Hz to 20 kHz
1/3 octave band fixed
(31 bands)
±12 dB
0.1 or 0.5 dB
steps
0.267 - 69.249
(96points)
Filter Type Cut-off Frequency Q
HPF(6 dB)
LPF(6 dB)
---
HPF(12 dB)
LPF(12 dB)
20 Hz to 20 kHz
1/24 octave band or
continuous variable type
(effective figure: 3 digits)
0.500 - 2.563
(51points)
Additional function : Band-bypass function, Bypass-all function
Amplitude frequency characteristic graph indication
Filter
No. of adjustment bands : 2 bands, 8 bands, 12 bands
Filter Type Center Frequency Boost/Cut Q
PEQ 20 Hz to 20 kHz
1/24 octave band or
continuous variable type
(effective figure: 3 digits)
±12 dB
0.1 or 0.5 dB
steps
0.267 - 69.249
(96points)
Filter Type Cut-off Frequency Q
HPF(6 dB)
LPF(6 dB)
---
HPF(12 dB)
LPF(12 dB)
20 Hz to 20 kHz
1/24 octave band or
continuous variable
type(effective figure: 3 digits)
0.500 - 2.563
(51points)
