Toa DP-0206 - Delay and Crossover Specifications

65
Filter Type Roll-off Frequency Boost/Cut
High Shelving 6 Hz to 20 kHz
1/24 octave band or
continuous variable type
(effective figure: 3 digits)
±12 dB
0.1 or 0.5 dB
steps
Low Shelving 20 Hz to 500 Hz
1/24 octave band or
continuous variable
type(effective figure: 3 digits)
±12 dB
0.1 or 0.5 dB
steps
Filter Type Center Frequency Q
Notch 20 Hz to 20 kHz
1/24 octave band or
continuous variable type
(effective figure: 3 digits)
8.65, 9.89,
11.54, 13.85,
17.31, 23.08,
34.62, 69.25
Filter Type Boost
Horn EQ 0 to +18 dB
0.5 dB steps
Additional function : Band-bypass function, Bypass-all function
Amplitude frequency characteristic graph indication
Delay
Delay time : 0 - 682.6 ms (0.021 ms steps)
Additional function : Distance input (meter, feet, inch)
