Crossover(2-way, 3-way, 4-way)
Slope Type Cut-off Frequency Q Q2
Through None
6 dB/oct
12 dB/oct Bessel,
12 dB/oct Butterworth
12 dB/oct Linkwitz-Riley
---
12 dB/oct Variable - Q 0.500 - 2.563
(51points)
18 dB/oct Bessel,
18 dB/oct Butterworth
---
18 dB/oct Variable - Q 0.500 - 2.563
(51points)
24 dB/oct Bessel,
24 dB/oct Butterworth
24 dB/oct Linkwitz-Riley
---
---
24 dB/oct Variable - Q
20 Hz to 20 kHz
continuous variable type
(effective figure: 3 digits)
0.500 - 2.563
(51points)
0.500 - 2.563
(51points)
Gain : +12 dB to -60 dB,-∞ dB 0.5 dB steps, polarity inversion possible
Delay : Maximum 682.6 ms
Level(Attn)
Variable range : 0 dB to -60 dB, -
∞ dB 0.5 dB steps
Muting
Provided in each output channel
