Tomey AL-4000 User Manual

3-9 䕔 
f) Connecting the corneal thickness/A-scan diagnosis probe
䕔 When using the pachymetry probe with a
disposable tip, pay extreme attention not to
allow air to enter the disposable tip. If air enters
the tip, measurement cannot be performed or
correct measurement cannot be obtained.

䕔
When using the pachymetry probe with a
disposable tip, press the “Calib (calibration)”
button and calibrate the sensitivity of the probe
after the disposable tip is replaced. Otherwise,
measurement cannot be performed or correct
measurement cannot be obtained.

1) Align the red marks and insert the connector of the corneal
thickness/A-scan diagnosis probe (1) to the corneal
thickness/A-scan diagnosis probe connector (2) at the bottom of the
instrument until a click is heard.
(1)
(2)
(Fig.
1)
