11
AC voltage, AC current
[2] [3]
[1]. Reading rate at 60-Hz and 50-Hz operating conditions, turning off auto zero, within a fixed range.
[2]. The number of display digits in the case of automatically displaying the number of digits. If a fixed number of
digits are selected, the number of displayed digits does not change due to the test speed.
[3]. The average speed at which the ADC continuously sampling to the data transmission and display.
[4]. Read data by instructions.
[5]. Add 20μV to DCV; increase resistance by 20 mΩ. When DCA increases by 0.2μA, 100uA, 10mA range, the
range error is increased by 10 times.
[6]. Read stable data. The actual ADC sampling speed is faster than the stable speed.
[7]. External trigger or remote operation, using the default stable delay (automatic delay).
[8]. Use the default maximum value, set the delay to expire.
Chapter 3 Specifications for TH1963
Technical description
Technical indicator assumption
One year calibration cycle
Operating temperature environment: 18 ° C ~ 28 ° C
Calibration temperature T
CAL
=23°C
It is calibrated after warming up for 60 minutes
Accuracy representation: ± (% reading + % range)
[1]
Operating humidity environment: at 0 °C ~ 18 °C (when the resistance range is ≥10M, ≤70% RH), ≤80%RH,
at 28°C ～40°C, ≤70%RH
3.1 Specification
DC voltage technical indicators
Temperature
coefficient/°C
[2]
