17
Filter: 3Hz (slow speed)
20Hz (medium, slow speed)
200Hz (fast, medium and slow speed)
Default: 20Hz filter, medium speed
Ω2W(Ω4W)
To configure the two-wire resistance test
Range: Auto Range (default) {10Ω, 100Ω, 1kΩ, 10kΩ, 100kΩ, 1MΩ, 10MΩ, 100MΩ}
NPLC: {0.02, 0.2, 1, 10, 100} Default: 10 PLC
Auto zero setting: OFF or ON (default: ON)
Shift +Ω2W(Ω4W)
To configure the four-wire resistance test
Range: Auto Range (default) {10Ω, 100Ω, 1kΩ, 10kΩ, 100kΩ, 1MΩ, 10MΩ, 100MΩ}
NPLC: {0.02, 0.2, 1, 10, 100} Default: 10 PLC
Freq (Temp)
To configure the frequency and period measurements
Filter: 3Hz, 20Hz, 200Hz
Gating time: 10ms, 100ms (default), 1s
Shift + Freq
(Temp)
To configuration the temperature test
Probe type: two-wire test (default) or four-wire test
R0: resistance at 0 °C, default: 100Ω
NPLC: {0.02, 0.2, 1, 10, 100} Default: 10 PLC
Unit: °C, °F, K,
Count (diode)
Conduction (continuous) configuration
Test range: 1kΩ
Test current: 1mA
Buzzer: ON (default) or OFF
Door threshold: default 10Ω, can be set separately
Shift + Cont
(diode)
Diode configuration
Test voltage range: 0~5V
Test current: 1mA
Buzzer: ON (default) or OFF
CAP(MATH)
Capacitance measurement configuration
Range: Auto (default) {1nF, 10F, 100nF, 1uF, 10uF, 100uF, 1mF, 10mF}
Shift+
CAP(MATH)
Math zero calculation (NULL), you can set parameters
dB/dBm operation
smoothing
scal: Mx+b, Percent
statistics
Limit
NULL (PrtSch)
Mathematical zeroing calculation, the calculated value is the current measured data
Shift+NULL
(PrtSch)
Print the picture and save the current display interface
R/S
Run or Stop
Trigger
Single trigger
Menu
Menu Settings
Display: display settings
Acquire: trigger option
