46 TMR4610 Operators Manual D4208-EN
SETTING
[display]
D.A.N.
NO.
OPTIONS [displayed]
BOLD=DEFAULT
DESCRIPTION
REMOTE SWITCH
MESSAGE
(RI IMSG)
1402
OPEN, --, +, *,0, 1,2,3,
4,5,6,7,8,9, A, B, C,
D, E, F, G, H, I, J, K, L,
M, N, O, P, Q, R, S, T, U,
-V, -W, -X, -Y, -Z
Message that is displayed for
remote input switch condition.
D.A.N. 1401 set to “switch”.
REMOTE 1 SWITCH
STATE
(R1STAT)
1403
OPEN/CLOSED
Set remote input line state
that displays message and/or
illuminates alarm lamp.
D.A.N. 1401 set to “switch”.
REMOTE 1 SWITCH
MESSAGE TIME
(R1TIME)
1404
0...2-9
Set how often the remote
switch message is displayed.
Once every 0-9 seconds.
D.A.N. 1401 set to “switch”.
REMOTE INPUT 2
(RMINP2)
1411
TR HOLD, INGRED, OFF,
PRESET, SWITCH, TARE, PRINT,
HOLD, NETGRS, M+, ZERO
Sets function of remote input
line on the remote port.
REMOTE 2 SWITCH
MESSAGE
(RI2MSG)
1412
OPEN, --, +, *,0, 1,2,3,
4,5,6,7,8,9, A, B, C,
D, E, F, G, H, I, J, K, L,
M, N, O, P, Q, R, S, T, U,
-V, -W, -X, -Y, -Z
Message that is displayed for
remote input condition.
D.A.N. 1411 set to “switch”.
REMOTE 2 SWITCH
STATE
(R2STAT)
1413
OPEN/CLOSED
Set remote input line state
that displays message and/or
illuminates alarm lamp.
D.A.N. 1411 set to “switch”.
REMOTE 2 SWITCH
MESSAGE TIME
(R2TIME)
1414
0...2-9
Set how often the remote
switch message is displayed.
Once every 1-9 seconds.
D.A.N. 1411 set to “switch”.
PROGRAM ID
(PRG ID)
1998
Example: 15FE16
Displays current software
version
ESTIMATED
WEIGHT
(EST WT)
1999
Enter weight value using key pad.
Then press enter.
Manually adjust Gross weight
of scale by changing
zero/balance. Press “on” to
continue.
MENU 2 – COMMUNICATIONS FEATURES
REMOTE
(REMOTE)
2001
OFF, ON, MLTLNE
If ON indicator communicates
with Cab Control Display
SCALE NUMBER
(SCL NO)
2002
1,2,3,4,5,6,7,8,9,10,11,12,
13,14,15,16,17,18,19,20,
21,22,23,24…….48
Select scale number for cab
control
communication
EXTERNAL RADIO
(EXTRAD)
2003
ON/OFF
Enables external radio to be
connected to the J905 port.
