D4208-EN TMR4610 Operators Manual 47
SETTING
[display]
D.A.N.
NO.
OPTIONS [displayed]
BOLD=DEFAULT
DESCRIPTION
DDL ATTACHED
(DDL)
2004
YES/NO
Enables connection of a DDL
(Data Down-Loader)
SCOREBOARD
MODE
(SCOREM)
2101
0,1,2,3,4,5,6,7,8,11,12,15,27,37,38
,39
Select scoreboard output
ZERO OUTPUT
(ZEROUT)
2102
Weight displayed= Then press
ZERO key and hold for three
seconds.
Allows zero/balance for
SCOREM #11 serial gross
weight.
FRONT PANEL
ZEROUT
(ZEROFP)
2103
OFF/ON
Allows use of the zero key to
zero/balance the serial gross
weight.
OPERATION
STATUS
(OPSTAT)
2111
0, 2
Select operating data to be
sent to a Remote Terminal
COM 1 BAUD RATE
(C1 BD)
2201
1200,2400, 4800, 9600, 14400,
19200, 38400, 57600, 115200
Sets baud rate for com port
#1
COM 1 PARITY
(C1 PA)
2202
NONE, ODD, EVEN
Sets parity for com port #1
COM 1 DATA BITS
(C1DATA)
2203
7, 8
Sets data bits for com port #1
COM 1 DELAY
(C1 DLY)
2204
0, .10, .25, .50, .75, 1-5
Selects seconds to delay
before advancing to next line.
COM 2 BAUD RATE
(C2 BD)
2211
1200,2400, 4800, 9600, 14400,
19200, 38400, 57600, 115200
Sets baud rate for com port
#2
COM 2 PARITY
(C2 PA)
2212
EVEN, ODD, NONE
Sets parity for com port #2
COM 2 DATA BITS
(C2DATA)
2213
7, 8
Sets data bits for com port #2
COM 2 DELAY
(C2 DLY)
2214
0, .10, .25, .50, .75, 1-5
Selects seconds to delay
before advancing to next line.
TARE AUTO PRINT
(TAREAP)
2301
ON/OFF
If ON -tare auto-prints
displayed weight.
ONE LINE PRINT
(1L PRT)
2302
ON/OFF
If ON -indicator data prints on
one line.
