Topcon DIGISTAR TMR4610 - Page 49

D4208-EN TMR4610 Operators Manual 49
SETTING
[display]
D.A.N.
NO.
OPTIONS [displayed]
BOLD=DEFAULT
DESCRIPTION
WM1 ADJUST 3
(WMA1-3)
3005
4000
Enter the weight to active
quick response weight
Default-10% of scale
capacity
WM2 ADJUST 1
(WMA2-1)
3006
30, value must be less than 100
and more than 2.
Increase this number to
smoothing weighing
WM2 ADJUST 2
(WMA2-2)
3007
10, value must be less than 100
and more than 0.
10=off. Use value less than
WMA2-1 for quick response
weight.
WM2 ADJUST 3
(WMA2-3)
3008
4000
Enter the weight to active
quick response weight
Default-10% of scale capacity
MOTION
(MOTION)
3101
ON/OFF
ON = Motion arrow flashes
with unstable weight.
Prevents: Print, Zero, Tare,
Advance
MOTION WEIGHT
(MOT WT)
3102
0
Enter weight used to detect
motion. 0=Standard
detection
MENU 4 - PRESET, ALARM, and TIMER
PRE-ALARM
METHOD
(P MTHD)
4001
WEIGHT, PERCENT
Select weight or percentage
method for pre-alarm
PRE-ALARM
(P-ALM)
4002
100
Enter a value to activate an
early warning that indicator is
reaching the preset.
ALARM OUTPUT
(AL OUT)
4003
OFF, PRESET, TR
Select preset or TR to control
relay, horn & lamp.
BUZZER
(BUZZER)
4004
OFF, ON, 1-10
ALARM BUZZER -allows user
to turn off alarm horn when
loading/unloading
RELAY
(RELAY)
4005
OFF, PRESET, SETPNT
Selects the behavior of the
+12VDC alarm output
PRESET DELAY
(PRTDLY)
4006
10
Set time to automatically
advance/print entered preset
GROSS SET PNT
OUTPUT (SETOUT)
4101
OVER/UNDER
Select when the +12VDC
Alarm Output becomes
active.
GROSS SET POINT
CHNG (SETCHG)
4102
500
Set required weight change to
turn off +12VDC Alarm
Output.
