1NOMENCLATURE AND FUNCTIONS
1-1
1 NOMENCLATURE AND FUNCTIONS
1.1 NOMENCLATURE
Mode 2 indicator /
Rotating Laser(RL) Battery Status Light
(operates with specific Topcon laser models only)
Detector
Display
Mode 1 indicator /
Laser sensor(LS) Battery
Status Light
Battery Holder Lock
Mode Selection Switch
Power Switch
Charging Status LED (only DB-54C)
External Connector (input/output)
Charging Connector (only DB-54C)
Battery Holder ( or cover)
Hand Grip / Mast Clamp
Detector
